2023-03-06

ansible安装使用入门

安装

准备

下载地址

https://github.com/ansible/ansible/releases

设置源

cs@debian:~$ cat ~/.pip/pip.conf
[global]
trusted-host=mirrors.aliyun.com
index-url=http://mirrors.aliyun.com/pypi/simple/

`get-pip.py`

This is a Python script that uses some bootstrapping logic to install pip.

Download the script, from https://bootstrap.pypa.io/get-pip.py.
Open a terminal/command prompt, cd to the folder containing the get-pip.py file and run:

Linux
1
$ python get-pip.py

No module named ‘distutils.cmd’ #依赖 python3.x-distutils

export PATH=”$HOME/.local/bin:$PATH”

开始

cd ansible-xxx

安装依赖

pip install –user -r ./requirements.txt

正式安装

python setup.py install

ansible –version

pkg_resources.DistributionNotFound: The ‘jinja2’

pip list 查看，执行用户没有安装该模板

使用

示例

使用root用户执行命令

-m 模块
-a 命令
–become 或 -b
–become-method [ sudo | su | pbrun | pfexec | doas | dzdo | ksu | runas | machinectl ]
–become-user
–ask-become-pass 或 -K

1	ansible node -m shell -a "cat /etc/docker/key.json" -b --become-method su --become-user root -K

BECOME password: 输入密码

group

❯ ansible --version
ansible [core 2.16.2]
  config file = /opt/ansible/ansible.cfg
❯ cat /opt/ansible/ansible.cfg | grep inventory
inventory = /opt/ansible/hosts
❯ ls /opt/ansible/hosts
dev  k8s  node

❯ ansible k8s-shell --list-hosts
[WARNING]: Invalid characters were found in group names but not replaced, use -vvvv to see details
  hosts (8):
    k8s01
    k8s02
    k8s03
    k8s04
    k8s05
    k8s06
    k8s07
    k8s08

copy

1 2	ansible test -m copy -a "src=/opt/zabbix/etc/zabbix_agentd.conf.d/agent.conf dest=/etc/zabbix/zabbix_agentd.d/" -b --become-method sudo --become-user root

shell/service

#k8s05   NotReady   <none>          461d   v1.26.1

ansible k8s05 -m shell -a "systemctl status kubelet"

ansible k8s05 -m service -a "name=kubelet state=started "

加密文件

对密码等保密信息进行加密

创建加密文件

设置文件密码,调用vi 编辑器,写入保密信息

1	ansible-vault create node-pass.yaml

cs@debian:/opt/ansible $cat node-pass.yaml $ ANSIBLE_VAULT;1.1;AES256
39336263626462323665333364313465343437613332656562383532366436363036373662336630
6666313066386532663833623237633833356235633765660a666631396236636136656239613062
62363333373961363239333735343061656638366537323332353335353861623137666232393037
3164633166613864360a383833386538343337326335636135323435313532346665336562356464
31363663633930653434633564656231663566303538393066346236363731386132

解密已加密文件

1	ansible-vault decrypt node-pass.yaml

cs@debian:/opt/ansible$ cat node-pass.yaml
-–
password: 123456

加密解密后的文件

1	ansible-vault encrypt node-pass.yaml

cs@debian:/opt/ansible $ ansible-vault encrypt node-pass.yaml New Vault password: Confirm New Vault password: Encryption successful cs@debian:/opt/ansible$ cat node-pass.yaml
$ANSIBLE_VAULT;1.1;AES256
64383861626430373864316636386430306463656436623238386238303537313964396238343133
3763333630643336333930333934653466393863366365390a386637343761376430613465333233
33643364633930346466646233356637333862653730663063636332653436353635643535376164
3061396164616266380a656239313837353632386562613531633539313461343764376139373838
38616631616565316264366436326665646665663866306161396132303236313234

编辑加密文件

1	ansible-vault edit node-pass.yaml

cs@debian:/opt/ansible$ ansible-vault edit node-pass.yaml
Vault password:

查看加密文件

仅查看的内容而不进行编辑

1	ansible-vault view node-pass.yaml

cs@debian:/opt/ansible$ ansible-vault view node-pass.yaml
Vault password:
-–
password: 123456

加密字符串

1	ansible-vault encrypt_string --vault-id dev@a_password_file '123456' --name 'become_pass'

cs@debian:/opt/ansible $ansible-vault encrypt_string --vault-id dev@a_password_file '123456' --name 'become_pass' become_pass: !vault | $ ANSIBLE_VAULT;1.2;AES256;dev
36636239393163616238326666343263613830363731333662373136313462613138356136616166
3264613139643933333663303938613539653963633038370a383961343836633937316362633437
33393836383734633838656130366666353838306234303762623966323764613465373865633865
6630323763396663300a303135353765613539306465363837653566613139353265373833613830
6135
Encryption successful

dev 代表标签
a_password_file 一个文件,里面是--vault-id @prompt 的值
‘123456’ 字符串的明文,即密码,不推荐这样操作
--name 指定变量名

ansible-playbook

引用加密文件

1	ansible-playbook /opt/ansible/yaml/local-b.yaml --vault-id @prompt

cs@debian:~$ ansible-playbook /opt/ansible/yaml/local-b.yaml –vault-id @prompt
Vault password (default): 输入保护文件的密码,解密文件内容

node-pass.yaml见创建加密文件

# /opt/ansible/yaml/local-b.yaml
---
- hosts: node
  vars_files:
    - /opt/ansible/node-pass.yaml
  tasks:
  - name: Run a command
    become: yes
    become_method: su
    vars:
       ansible_become_pass: "{{ password }}"
    file:
      state: absent
      path: /opt/kubernetes/amd64/kube-apiserver

vars_files 引入文件

file 操作文件的模块

file模块主要用于远程主机上的文件操作

force：需要在两种情况下强制创建软链接，一种是源文件不存在但之后会建立的情况下；另一种是目标软链接已存在,需要先取消之前的软链，然后创建新的软链，有两个选项：yes|no
group：定义文件/目录的属组
mode：定义文件/目录的权限
owner：定义文件/目录的属主
path：必选项，定义文件/目录的路径
recurse：递归的设置文件的属性，只对目录有效
src：要被链接的源文件的路径，只应用于state=link的情况
dest：被链接到的路径，只应用于state=link的情况
state： directory：如果目录不存在，创建目录
file：即使文件不存在，也不会被创建
link：创建软链接
hard：创建硬链接
touch：如果文件不存在，则会创建一个新的文件，如果文件或目录已存在，则更新其最后修改时间
absent：删除目录、文件或者取消链接文件

引用文件内加密变量

1	ansible-playbook /opt/ansible/yaml/local-b.yaml --vault-password-file /opt/ansible/a_password_file

custom.yaml 见创建加密变量

# 加密变量
---
custom_vars:
    become_pass: !vault |
          $ANSIBLE_VAULT;1.2;AES256;dev
          66383637343038636234353234353062633966663738616666653931353730333839653362373935
          6632343665313561333435323366376661343065636133340a373866373835303731383034653663
          31633938616330343535393339626163656630323233316566393264306462666434303434383263
          6333386535323666330a623965623436373464653734383736663464356664343439343837613039
          3635

local-b.yaml

---
- hosts: node
  vars_files:
    - /opt/ansible/custom.yaml
  tasks:
  - name: Run a command
    become: yes
    #become_user: root
    become_method: su
    vars:
       ansible_become_pass: "{{ custom_vars.become_pass }}"
    file:
      state: absent
      path: /opt/kubernetes/amd64/kube-apiserver

调试

check检查语法

1	ansible-playbook --syntax-check xxx.yaml

debug

1	ansible-playbook xxx.yaml --tags debug -vvvv

-vvvv 详细等级，v越多越详细
